BODIPY 493/503  (Synonyms: Pyrromethene 546; BDP 493/503 lipid stain)

Cat. No.: HY-W090090 Purity: 99.63%
Handling Instructions Technical Support

BODIPY493/503 is a BODIPY dye. BODIPY dye is a small molecule dye with strong ultraviolet absorption ability, its fluorescence peak is relatively sharp, and the quantum yield is high. They are relatively insensitive to the polarity and pH of the environment and are relatively stable under different physiological conditions. Due to its structural asymmetry, BODIPY derives a variety of structural products. BODIPY lipid droplet dyes can well pass through the cell membrane into the cell, and localize the neutral lipids in the cell to specifically stain the lipid droplets, which can be used for labeling of live cells and fixed cells. Maximum excitation/emission wavelength: 493/503 nm.

For research use only. We do not sell to patients.

BODIPY 493/503 Chemical Structure

BODIPY 493/503 Chemical Structure

CAS No. : 121207-31-6

Size Price Stock Quantity
Free Sample (0.1 - 0.5 mg)   Apply Now
5 mg In-stock
10 mg In-stock
25 mg In-stock
50 mg In-stock
100 mg In-stock
200 mg   Get quote
500 mg   Get quote

* Please select Quantity before adding items.

This product is a controlled substance and not for sale in your territory.

Customer Review

Based on 41 publication(s) in Google Scholar

Top Publications Citing Use of Products

34 Publications Citing Use of MCE BODIPY 493/503

IF

    BODIPY 493/503 purchased from MedChemExpress. Usage Cited in: Nat Commun. 2025 Feb 1;16(1):1241.  [Abstract]

    BODIPY 493/503 (0.2 μg/mL; 30 min). Neutral lipids stained with the BODIPY 493/503 probe in the control and FLAD1 knockdown SUM159 cells or in the HCC1806 cells

    BODIPY 493/503 purchased from MedChemExpress. Usage Cited in: Environ Sci Technol. 2025 Jan 2.  [Abstract]

    BODIPY 493/503 (2 μM; 15 min). BODIPY 493/503 staining of lipids in HepG2 cells.

    BODIPY 493/503 purchased from MedChemExpress. Usage Cited in: Int J Biol Macromol. 2025 Jan 28:301:140458.  [Abstract]

    BODIPY 493/503 (2 μg/mL; 15 min). At the end of culturing, cells were fixed and stained with BODIPY 493/503, and images were taken under a fluorescence microscope; scale bar: 200 μm.

    BODIPY 493/503 purchased from MedChemExpress. Usage Cited in: Phytomedicine. 2025 Feb 2:139:156445.  [Abstract]

    BODIPY 493/503 (1 µM; 1 h). Representative images and quantitative results of BODIPY staining (scale bars, 20 µm) in AML-12 cells. (n = 5 per group)

    BODIPY 493/503 purchased from MedChemExpress. Usage Cited in: Cell Mol Life Sci. 2024 Sep 11;81(1):398.  [Abstract]

    BODIPY 493/503 (5 µM; 30 min). BODIPY staining of PA-induced steatosis hepatocytes.

    BODIPY 493/503 purchased from MedChemExpress. Usage Cited in: Food Chem X. 2024 Oct 30.

    BODIPY 493/503 (5 µM; 30 min). Representative images of immunofluorescence staining of MSCs-derived myotubes on NLV scaffolds after 7 days in differentiation media. Green: Desmin; Blue: Veins. Scale bars: 100 μm.

    BODIPY 493/503 purchased from MedChemExpress. Usage Cited in: Mbio. 2024 Jan 23:e0319723.  [Abstract]

    BODIPY 493/503 (10 min. Marc-145 cells were transfected with siSREBF1 or siNC and then infected with PEDV (MOI = 1) for 24 h. The contents of cellular lipid droplets (green) and the nuclei (blue) were detected by immunofluorescence assay. Scale bar, 10 µm. The fluorescence intensity of lipids was analyzed with ImageJ.
    • Biological Activity

    • Purity & Documentation

    • References

    • Customer Review

    Description

    BODIPY493/503 is a BODIPY dye. BODIPY dye is a small molecule dye with strong ultraviolet absorption ability, its fluorescence peak is relatively sharp, and the quantum yield is high. They are relatively insensitive to the polarity and pH of the environment and are relatively stable under different physiological conditions. Due to its structural asymmetry, BODIPY derives a variety of structural products. BODIPY lipid droplet dyes can well pass through the cell membrane into the cell, and localize the neutral lipids in the cell to specifically stain the lipid droplets, which can be used for labeling of live cells and fixed cells[1]. Maximum excitation/emission wavelength: 493/503 nm[1].

    In Vitro

    General Protocol
    1. Preparation of BODIPY 493/503 working solution
    1.1 Preparation of the stock solution
    Dissolve 1 mg BODIPY 493/503 in 382 μL DMSO to obtain 10 mM of stock solution.
    Note: It is recommended to store the stock solution at -20°C or -80°C, keep away from light and avoid repetitive freeze-thaw cycles.
    1.2 Preparation of BODIPY 493/503 working solution
    Dilute the stock solution in serum-free cell culture medium or PBS to obtain 1-10 μM of working solution.
    Note: Please adjust the concentration of BODIPY 493/503 working solution according to the actual situation.
    2. Cell staining
    2.1 Suspension cells (6-well plate)
    a. Centrifuge at 1000 g at 4°C for 3-5 min and then discard the supernatant. Wash twice with PBS, 5 min each time.The cell density is 1×106/mL.
    b. Add 1 mL of working solution, and then incubate at room temperature for 5-30 min.
    c.Centrifuge at 400 g at 4°C for 3-4 min and then discard the supernatant.
    d. Wash twice with PBS, 5 min each time.
    e. Resuspend cells with serum-free cell culture medium or PBS. Observation by fluorescence microscopy or flow cytometry.
    2.2 Adherent cells
    a. Culture adherent cells on sterile coverslips.
    b. Remove the coverslip from the medium and aspirate excess medium.
    c. Add 100 μL of working solution, gently shake it to completely cover the cells,and then incubate at room temperature for 5-30 min.
    d. Wash twice with medium, 5 min each time. Observation by fluorescence microscopy or flow cytometry.

    Storage
    -20°C, 1 year; Protect from light.
    Precautions
    1. Please adjust the concentration of BODIPY 493/503 working solution according to the actual situation.
    2. Experiments suggest a positive control, incubate the control group cells with 30 μM oleic acid for 8 h and then perform subsequent experiments.
    3. This product is only for R&D use, not for drug, household, or others.
    4. For your safety and health, please wear a lab coat and disposable gloves to operate.

    MedChemExpress (MCE) has not independently confirmed the accuracy of these methods. They are for reference only.

    Molecular Weight

    262.11

    Formula

    C14H17BF2N2

    CAS No.
    Appearance

    Solid

    Color

    Brown to reddish brown

    Emission (Em)

    503

    Excitation (Ex)

    493

    SMILES

    [F-][B+3]1([N]2=C(C)C=C(C)C2=C(C)C3=C(C)C=C(C)[N-]31)[F-]

    Shipping

    Room temperature in continental US; may vary elsewhere.

    Storage

    4°C, sealed storage, away from moisture and light

    *In solvent : -80°C, 6 months; -20°C, 1 month (sealed storage, away from moisture and light)

    Solvent & Solubility
    In Vitro:

    DMSO : 5 mg/mL (19.08 mM; ultrasonic and warming and heat to 60°C; Hygroscopic DMSO has a significant impact on the solubility of product, please use newly opened DMSO)

    Preparing
    Stock Solutions
    Concentration Solvent Mass 1 mg 5 mg 10 mg
    1 mM 3.8152 mL 19.0760 mL 38.1519 mL
    5 mM 0.7630 mL 3.8152 mL 7.6304 mL
    View the Complete Stock Solution Preparation Table

    * Please refer to the solubility information to select the appropriate solvent. Once prepared, please aliquot and store the solution to prevent product inactivation from repeated freeze-thaw cycles.
    Storage method and period of stock solution: -80°C, 6 months; -20°C, 1 month (sealed storage, away from moisture and light). When stored at -80°C, please use it within 6 months. When stored at -20°C, please use it within 1 month.

    • Molarity Calculator

    • Dilution Calculator

    Mass (g) = Concentration (mol/L) × Volume (L) × Molecular Weight (g/mol)

    Mass
    =
    Concentration
    ×
    Volume
    ×
    Molecular Weight *

    Concentration (start) × Volume (start) = Concentration (final) × Volume (final)

    This equation is commonly abbreviated as: C1V1 = C2V2

    Concentration (start)

    C1

    ×
    Volume (start)

    V1

    =
    Concentration (final)

    C2

    ×
    Volume (final)

    V2

    In Vivo Dissolution Calculator
    Please enter the basic information of animal experiments:

    Dosage

    mg/kg

    Animal weight
    (per animal)

    g

    Dosing volume
    (per animal)

    μL

    Number of animals

    Recommended: Prepare an additional quantity of animals to account for potential losses during experiments.
    Calculation results:
    Working solution concentration: mg/mL
    Purity & Documentation

    Purity: 99.63%

    References

    Complete Stock Solution Preparation Table

    * Please refer to the solubility information to select the appropriate solvent. Once prepared, please aliquot and store the solution to prevent product inactivation from repeated freeze-thaw cycles.
    Storage method and period of stock solution: -80°C, 6 months; -20°C, 1 month (sealed storage, away from moisture and light). When stored at -80°C, please use it within 6 months. When stored at -20°C, please use it within 1 month.

    Optional Solvent Concentration Solvent Mass 1 mg 5 mg 10 mg 25 mg
    DMSO 1 mM 3.8152 mL 19.0760 mL 38.1519 mL 95.3798 mL
    5 mM 0.7630 mL 3.8152 mL 7.6304 mL 19.0760 mL
    10 mM 0.3815 mL 1.9076 mL 3.8152 mL 9.5380 mL
    15 mM 0.2543 mL 1.2717 mL 2.5435 mL 6.3587 mL
